Name: 4.0 Inch Color IPS LCD Screen 400x960 Touchscreen Display Module 350 cd/m2
Brand: Shenzhen Dingruishi Technology Co., Ltd
SKU: DRS040-V1
Price: 22.00 USD
Availability: InStock

Home > Products > TFT LCD Display Module >

4.0 Inch Color IPS LCD Screen 400x960 Touchscreen Display Module 350 cd/m2

4.0 Inch Color IPS LCD Screen

Color IPS LCD Screen 400x960

Touchscreen Display Module 350 cd/m2

Place of Origin:

Shenzhen, China

Brand Name:

Dingruishi

Certification:

CE, RoHS, ISO9001

Model Number:

DRS040-V1

Document:

Sepcification_DRS 040BHD868...V1.pdf

Chat Now

Request A Quote

Product Details

Brightness:

350 Cd/m²

Diagonal Size:

4.0 Inch

Module Dimensions:

42.5(H)*102.08(V)*2.16(D)

Pixel Pitch:

0.3265*RGB*0.9795

Interface Type:

3SPI+18RGB

Drive IC:

ST7701S

Highlight:

4.0 Inch Color IPS LCD Screen

Color IPS LCD Screen 400x960

Touchscreen Display Module 350 cd/m2

Payment & Shipping Terms

Minimum Order Quantity

100pcs

Price

15-30 USD

Packaging Details

20cm * 30cm * 40cm

Delivery Time

5-8 working days

Payment Terms

T/T

Supply Ability

500,000pcs per week

2.95 Inch 480x854 TFT LCD Screen Module 350 cd/m2 LCD Touch Display Module

Chat Now

video

3.95 Inch TFT LCD Display Module 350 cd/m2 Square TFT Display 720x720

Chat Now

video

300 cd/m2 TFT LCD Display Module Display 2.0 Inch 240x320 IPS Display Module

Chat Now

video

1920x1080 TFT LCD Module 30pin eDP Display 13.3 Inch WLED Backlight

Chat Now

86--15875570275

linda@lcdtftscreens.com

Chat Now

Product Description

4.0 Inch TFT LCD Display Module with 400x960 Resolution and IPS Full Viewing Angle for Embedded Projects

Our 4.0 Inch TFT LCD Display Module is an all-in-one solution designed for embedded systems, DIY projects, and compact electronic devices that require seamless integration and high performance. This module integrates a 4.0 inch TFT LCD screen, a built-in driver board, and optional capacitive touch panel (CTP), eliminating the need for additional components and simplifying the integration process for engineers and developers.

Featuring a resolution of 400x960 pixels, this display module delivers sharp, detailed images with 16.7M colors, ensuring vivid color reproduction and clear text display. It supports RGB+9b_3SPI (rising edge) and RGB+16b_3SPI (falling edge) interfaces, offering flexible compatibility with a wide range of microcontrollers and embedded platforms. The optional CTP touch panel provides precise touch response, making it ideal for devices that require user interaction, such as handheld terminals and smart controllers.

Built with a compact outline dimension of 43.30x102.95x2.52mm, this module is designed to fit into space-constrained devices, while its robust construction ensures long-term reliability. The module operates at a typical voltage of 3.3V, with a backlight voltage of 22.5~27.2V and current of 20mA, balancing performance and power consumption. It is equipped with the ST7701S driver IC, ensuring stable operation and fast data transmission, even in demanding applications. Additionally, the module includes protection against image retention, with recommendations to refresh fixed patterns every 2 minutes or less.

Note1: The LED driving condition is defined for each module.

Note2: When LCM is operated, the stable forward current should be inputted. And forward voltage is for reference only.

Note3: Optical performance should be evaluated at Ta=25℃ When LED is driven at high current, high ambient temperature & humidity condition. The life time of LED will be reduced. Operating life means brightness goes down to 50% initial brightness. Typical operating life time is estimated data.

Note4: The LED driving condition is defined for each LED module.

Technical Specifications

Model Number	DRS040-V1
Display Size	4.0 inches
Resolution	400(RGB)x960
Brightness	350 cd/m² (nits)
Interface Type	RGB24
Touch Screen	Capacitive / CTP Resistive Touch
Viewing Angle	170°+ (Full View)
Cover Lens	Black Glass / Anti-glare IPS
Operation Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C
Packing Size	20cm × 30cm × 40cm
Minimum Order Quantity	100 pieces

Product Advantages

IPS Full Viewing Angle: Ensures consistent color and brightness from all viewing directions, eliminating distortion and improving user experience.
Ultra-Low Power Consumption: Semi-transflective design allows use without backlight in natural light, reducing power usage for longer device battery life.
Easy Installation: 40PIN FPC flexible cable connection enables simple disassembly and assembly, suitable for space-constrained devices.
Stable Performance: ST7701 driver chip optimizes display functionality, ensuring smooth operation and accurate image rendering.
Global Compliance: RoHS compliant, meeting international environmental and safety standards for global market access.

Application Fields

The 4.0 Inch TFT LCD Display Module is ideal for a variety of embedded and DIY applications, including:

Embedded development projects (e.g., Raspberry Pi, Arduino, ESP32-based projects)
DIY electronic kits (e.g., custom smart devices, hobbyist projects)
Handheld terminals (e.g., data collection devices, portable scanners)
Smart home controllers (e.g., centralized control panels, environmental monitors)
Medical devices (e.g., portable diagnostic tools, wearable health monitors)
