Name: 1920x1080 Industrial Touch Screen Panel Wide Temp TFT Display Screen 13.3 Inch
Brand: Shenzhen Dingruishi Technology Co., Ltd
SKU: 133FHB-N81
Price: 53.00 USD
Availability: InStock

Home > Products > Industrial TFT Display >

1920x1080 Industrial Touch Screen Panel Wide Temp TFT Display Screen 13.3 Inch

1920x1080 Industrial Touch Screen Panel

Wide Temp TFT Display Screen

TFT Display Screen 13.3 Inch

Place of Origin:

Shenzhen, China

Brand Name:

Dingruishi

Certification:

CE, RoHS, ISO9001

Model Number:

133FHB-N81

Document:

B8 Product Spec QV133FHB-N8...2.pptx

Chat Now

Request A Quote

Product Details

Model:

QV133FHB-N81-8D32

Size:

13.3” Diagonal

Resolution:

1920×1080 (FHD)

Panel Type:

A-Si TFT-LCD, CELL, FOB

Active Area:

293.76 (W) × 165.24 (H) Mm

Interface:

EDP 30pin

Outline Dim:

307.6×183.05×5.5mm

Viewing Angle:

85/85/85/85 (L/R/U/D)

Refresh Rate:

60Hz

Input Voltage:

3.3V (signal)

Highlight:

1920x1080 Industrial Touch Screen Panel

Wide Temp TFT Display Screen

TFT Display Screen 13.3 Inch

Payment & Shipping Terms

Minimum Order Quantity

100pcs

Price

39-67 USD

Packaging Details

20cm * 30cm * 40cm

Delivery Time

5-8 working days

Payment Terms

T/T

Supply Ability

500,000pcs per week

400 cd/m2 Industrial TFT Display 3.95 Inch TFT IPS Screen 480x480 For High Definition Visuals

Chat Now

video

3.95 Inch Industrial TFT Display 720x720 IPS Panel Display 400 cd/m2

Chat Now

video

350 cd/m2 Industrial Touch Screen Display High Contrast 4 Inch TFT Screen 720x720 For Harsh Environments

Chat Now

video

5.5 Inch Industrial TFT Display Anti Interference Industrial Touch Screen High Definition

Chat Now

86--15875570275

linda@lcdtftscreens.com

Chat Now

Product Description

QV133FHB-N81-8D32 | 13.3” Industrial TFT Display | High Durability Wide Temp

The QV133FHB-N81-8D32 is a 13.3-inch rugged industrial TFT display optimized for harsh industrial environments. Built on BOE’s industrial-grade a-Si TFT-LCD technology, it features a Full HD 1920×1080 resolution, 600cd/m² high brightness, and an extended operating temperature range of -20°C to +60°C (storage: -30°C to +70°C). The display incorporates enhanced shock/vibration resistance, anti-glare surface treatment, and a long-life WLED backlight, making it ideal for factory automation, outdoor kiosks, and medical equipment.

Application Fields

Factory automation & industrial control panels
Outdoor kiosks & digital signage
Medical equipment (diagnostic monitors)
Transportation (in-vehicle displays, marine systems)

Advantages

Extended Temperature Tolerance: Operates reliably in extreme cold/heat
Rugged Industrial Design: Withstands shock, vibration, and harsh chemicals
Enhanced Visibility: Anti-glare coating for bright industrial environments
Long-Term Reliability: 70,000hrs lifespan for 24/7 industrial operation
