Wide Temp Industrial Touchscreen Display 15.6 Inch Industrial Panel Display 1920x1080

Wide Temp Industrial Touchscreen Display 15.6 Inch Industrial Panel Display 1920x1080

Wide Temp Industrial Touchscreen Display

Industrial Touchscreen Display 15.6 Inch

Industrial Panel Display 1920x1080

Place of Origin:

Shenzhen, China

Brand Name:

Dingruishi

Certification:

CE, RoHS, ISO9001

Model Number:

NE156FH1

Document:

YSJ-NE156FH1-B42 .pdf

Chat Now
Request A Quote
Wide Temp Industrial Touchscreen Display 15.6 Inch Industrial Panel Display 1920x1080
Wide Temp Industrial Touchscreen Display 15.6 Inch Industrial Panel Display 1920x1080 Wide Temp Industrial Touchscreen Display 15.6 Inch Industrial Panel Display 1920x1080 Wide Temp Industrial Touchscreen Display 15.6 Inch Industrial Panel Display 1920x1080
Product Details
Model:
YSJ-NE156FH1-B42
Size:
15.6” Diagonal
Resolution:
1920×1080 (FHD)
Panel Type:
A-Si TFT-LCD, CELL, FOB
Active Area:
293.76 (W) × 165.24 (H) Mm
Interface:
EDP 30pin (1 Lane)
Outline Dim:
359.5×223.8×6.5mm
Viewing Angle:
85/85/85/85 (L/R/U/D)
Brightness:
300 Cd/m² (Typ.)
Input Voltage:
3.3V (signal)
Highlight:

Wide Temp Industrial Touchscreen Display

,

Industrial Touchscreen Display 15.6 Inch

,

Industrial Panel Display 1920x1080

Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
39-67 USD
Packaging Details
20cm * 30cm * 40cm
Delivery Time
5-8 working days
Payment Terms
T/T
Supply Ability
500,000pcs per week
RELATED PRODUCTS
Good price 400 cd/m2 Industrial TFT Display 3.95 Inch TFT IPS Screen 480x480 For High Definition Visuals online video

400 cd/m2 Industrial TFT Display 3.95 Inch TFT IPS Screen 480x480 For High Definition Visuals

Chat Now
Good price 3.95 Inch Industrial TFT Display 720x720 IPS Panel Display 400 cd/m2 online video

3.95 Inch Industrial TFT Display 720x720 IPS Panel Display 400 cd/m2

Chat Now
Good price 350 cd/m2 Industrial Touch Screen Display High Contrast 4 Inch TFT Screen 720x720 For Harsh Environments online video

350 cd/m2 Industrial Touch Screen Display High Contrast 4 Inch TFT Screen 720x720 For Harsh Environments

Chat Now
Good price 5.5 Inch Industrial TFT Display Anti Interference Industrial Touch Screen High Definition online video

5.5 Inch Industrial TFT Display Anti Interference Industrial Touch Screen High Definition

Chat Now
CONTACT US
86--15875570275
linda@lcdtftscreens.com
Chat Now
Product Description
YSJ-NE156FH1-B42 | 15.6” Industrial TFT Display | Rugged Wide Temperature Screen

The YSJ-NE156FH1-B42 is a 15.6-inch rugged industrial TFT display optimized for challenging industrial and outdoor environments. Built with enhanced a-Si TFT-LCD technology, it features a Full HD 1920×1080 resolution, 350 cd/m² high brightness, and an extended operating temperature range of -10°C to +60°C. This industrial display incorporates shock/vibration resistance, anti-glare surface treatment, and a reinforced WLED backlight (50,000hrs lifespan), making it ideal for factory automation, outdoor kiosks, and medical equipment requiring reliable 24/7 operation.


Application Fields




  • Factory automation & industrial control panels
  • Outdoor kiosks & digital signage
  • Medical equipment (diagnostic monitors)
  • Transportation (in-vehicle displays)
  •



Advantages




  • Extended Temperature Tolerance: Operates reliably in cold/heat
  • Rugged Industrial Build: Withstands shock, vibration, and dust
  • Anti-Glare Coating: Reduces reflections in bright environments
  • Long Lifespan: 50,000hrs backlight for 24/7 industrial use
