480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications

480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications

480x272 TFT LCD Display

TFT LCD Display 300 cd/m2

300 cd/m2 5 Inch LCD Display

Place of Origin:

Shenzhen, China

Brand Name:

Dingruishi

Certification:

CE, RoHS, ISO9001

Model Number:

DRS050-V1

Chat Now
Request A Quote
480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications
480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications
Product Details
Brightness(cd/m²):
300
Interface:
40p RGB
Resolution:
480*272
Supply Ability:
500,000pcs Per Week
Delivery Time:
5-8 Working Days
Minimum Order Quantity:
100pcs
Highlight:

480x272 TFT LCD Display

,

TFT LCD Display 300 cd/m2

,

300 cd/m2 5 Inch LCD Display

Payment & Shipping Terms
Minimum Order Quantity
100pcs
Price
Please contact us for latest price
Packaging Details
20cm * 30cm * 40cm
Delivery Time
5-8 working days
Payment Terms
T/T
Supply Ability
500,000pcs per week
RELATED PRODUCTS
Good price 800x480 7 Inch TFT Screen 300 cd/m2 Industrial LCD Displays For Industrial Applications online video

800x480 7 Inch TFT Screen 300 cd/m2 Industrial LCD Displays For Industrial Applications

Chat Now
Good price 300 cd/m2 TFT LCD Display Compact 5 Inch TFT Touch Screen 800x480 online video

300 cd/m2 TFT LCD Display Compact 5 Inch TFT Touch Screen 800x480

Chat Now
Good price 5.0 Inch TFT And IPS Display 300 Nits RGB Displays For Industrial Automotive Medical online video

5.0 Inch TFT And IPS Display 300 Nits RGB Displays For Industrial Automotive Medical

Chat Now
Good price 480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications online video

480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications

Chat Now
CONTACT US
86--15875570275
linda@lcdtftscreens.com
Chat Now
Product Description
Dingruishi DRS050 5.0'' Inch TFT LCD Module with 480x272 Resolution and 300 cd/m² Brightness for Industrial Applications
This compact 5.0-inch TFT LCD module provides a versatile display solution for embedded and industrial applications. Featuring a resolution of 480 * 272 pixels, it delivers clear, detailed visuals ideal for user interfaces, control panels, and multimedia displays. With 300 nits brightness, the screen ensures reliable performance in indoor environments with excellent visibility under standard lighting conditions.
Technical Specifications
Model Number DRS050-V1
Display Size 5.0''
Resolution 480 * 272 pixels
Brightness 300 cd/m² (nits)
Interface Type 40-pin RGB
Touch Screen Capacitive / CTP Resistive Touch
Viewing Angle 170°+ (Full View)
Cover Lens Black Glass / Anti-glare
Operation Temperature -20°C to 70°C
Storage Temperature -30°C to 80°C
Packing Size 20cm * 30cm * 40cm
Minimum Order Quantity 100pcs
Key Features
  • 40-pin RGB interface for broad compatibility
  • Capacitive touch screen with resistive touch option
  • Wide 170°+ viewing angle for optimal visibility
  • Industrial-grade temperature range operation
  • Black glass cover lens with anti-glare protection
  • Compact form factor for space-constrained applications
Applications
Industrial Control Systems, Human-Machine Interfaces (HMI), Medical Equipment, Automotive Displays, IoT Devices, DIY Electronics, and Commercial Products
Supported by the 40-pin RGB interface, this TFT LCD module meets industry standards with its robust temperature specifications, making it perfect for diverse applications from DIY electronics to commercial products requiring reliable display performance.
