Name: 1920x1080 Full HD LCD Screen 30pin eDP Panel 13.3 Inch QV133FHB-N81-8D32
Brand: Shenzhen Dingruishi Technology Co., Ltd
SKU: 133FHB-N81
Price: 53.00 USD
Availability: InStock

Home > Products > TFT LCD Display >

1920x1080 Full HD LCD Screen 30pin eDP Panel 13.3 Inch QV133FHB-N81-8D32

1920x1080 Full HD LCD Screen

30pin eDP Panel

eDP Panel 13.3 Inch

Place of Origin:

Shenzhen, China

Brand Name:

Dingruishi

Certification:

CE, RoHS, ISO9001

Model Number:

133FHB-N81

Document:

B8 Product Spec QV133FHB-N8...2.pptx

Chat Now

Request A Quote

Product Details

Model:

QV133FHB-N81-8D32

Size:

13.3” Diagonal

Resolution:

1920×1080 (FHD)

Panel Type:

A-Si TFT-LCD, CELL, FOB

Active Area:

293.76 (W) × 165.24 (H) Mm

Interface:

EDP 30pin

Outline Dim:

307.6×183.05×5.5mm

Viewing Angle:

85/85/85/85 (L/R/U/D)

Refresh Rate:

60Hz

Input Voltage:

3.3V (signal)

Highlight:

1920x1080 Full HD LCD Screen

30pin eDP Panel

eDP Panel 13.3 Inch

Payment & Shipping Terms

Minimum Order Quantity

100pcs

Price

39-67 USD

Packaging Details

20cm * 30cm * 40cm

Delivery Time

5-8 working days

Payment Terms

T/T

Supply Ability

500,000pcs per week

800x480 7 Inch TFT Screen 300 cd/m2 Industrial LCD Displays For Industrial Applications

Chat Now

video

300 cd/m2 TFT LCD Display Compact 5 Inch TFT Touch Screen 800x480

Chat Now

video

5.0 Inch TFT And IPS Display 300 Nits RGB Displays For Industrial Automotive Medical

Chat Now

video

480x272 TFT LCD Display 300 cd/m2 5 Inch LCD Display For Industrial Applications

Chat Now

86--15875570275

linda@lcdtftscreens.com

Chat Now

Product Description

QV133FHB-N81-8D32 | 13.3” FHD TFT LCD Display Panel | BOE Original

The QV133FHB-N81-8D32 is a 13.3-inch a-Si TFT-LCD bare panel manufactured by BOE, featuring a Full HD 1920×1080 resolution and 166PPI pixel density. As a core LCD cell without a driver board or touch overlay, it delivers crisp visuals with 600cd/m² typical brightness, 1000:1 contrast ratio, and 16.7 million color depth. The eDP 30pin interface ensures low-power, high-speed signal transmission, while the 5.5mm ultra-thin profile suits slim notebook and embedded device designs.

Application Fields

Notebook & laptop replacement screens
Entry-level embedded display projects
Consumer electronics bare display integration
Educational device LCD panel upgrades

Advantages

Original BOE Quality: Reliable performance with strict factory testing
FHD Visual Clarity: 1920×1080 resolution for sharp, detailed images
Slim & Lightweight: 5.5mm thickness ideal for portable devices
Cost-Effective: Bare panel design reduces integration costs
