Name: 480x800 LCD TFT Panel 4 Inch Round TFT LCD Display With IPS Full Viewing Angle
Brand: Shenzhen Dingruishi Technology Co., Ltd
SKU: DRS040-V1
Price: 17.00 USD
Availability: InStock

Home > Products > LCD TFT Screen >

480x800 LCD TFT Panel 4 Inch Round TFT LCD Display With IPS Full Viewing Angle

480x800 LCD TFT Panel

LCD TFT Panel 4 Inch

Round TFT LCD Display 480x800

Place of Origin:

Shenzhen, China

Brand Name:

Dingruishi

Certification:

CE, RoHS, ISO9001

Model Number:

DRS040-V1

Document:

Sepcification_DRS 040BHD868...V1.pdf

Chat Now

Request A Quote

Product Details

Brightness:

350 Cd/m²

Diagonal Size:

4.0 Inch

Module Dimensions:

42.5(H)*102.08(V)*2.16(D)

Pixel Pitch:

0.3265*RGB*0.9795

Interface Type:

3SPI+18RGB

Drive IC:

ST7701S

Highlight:

480x800 LCD TFT Panel

LCD TFT Panel 4 Inch

Round TFT LCD Display 480x800

Payment & Shipping Terms

Minimum Order Quantity

100pcs

Price

10-25 USD

Packaging Details

20cm * 30cm * 40cm

Delivery Time

5-8 working days

Payment Terms

T/T

Supply Ability

500,000pcs per week

6.9 Inch LCD TFT Display 280x1424 Resolution High Brightness LCD Display 350 cd/m2

Chat Now

video

2.4 Inch LCD TFT Screen 240x320 IPS Display Panel Normally Black

Chat Now

video

2.95 Inch IPS Display Screen Wide View TFT LCD Display 480X854 Resolution

Chat Now

video

350 cd/m2 LCD TFT Screen 3.95 Inch Square Display Screen 720x720 RGB

Chat Now

86--15875570275

linda@lcdtftscreens.com

Chat Now

Product Description

4.0 Inch LCD TFT Screen with IPS Full Viewing Angle and RGB Interface for Clear and Consistent Display

Our 4.0 Inch LCD TFT Screen is a high-performance display solution designed for compact electronic devices that require clear, consistent visual output. Engineered with advanced a-Si TFT technology, this screen delivers a resolution of 480x800 pixels, ensuring sharp text, vivid colors, and smooth image rendering for an exceptional viewing experience. Featuring an IPS full viewing angle design, it provides consistent color and brightness from all directions—whether viewed head-on or at a 80° angle, the display remains clear and distortion-free, making it ideal for devices used by multiple users or in varied viewing positions.

With a brightness of 100cd/m² and a semi-transflective design, this LCD TFT screen achieves ultra-low power consumption while maintaining excellent visibility in both natural and low-light environments. It uses a 40PIN FPC flexible cable connection, which ensures secure electrical transmission and easy installation, even in space-constrained devices. Powered by the ST7701 driver chip, the screen operates stably with fast data transmission, supporting seamless integration with STM32 and RK series motherboards via the RGB interface. Every unit is RoHS compliant, adhering to strict environmental and safety standards for global markets.

Note1: The LED driving condition is defined for each module.

Note2: When LCM is operated, the stable forward current should be inputted. And forward voltage is for reference only.

Note3: Optical performance should be evaluated at Ta=25℃ When LED is driven at high current, high ambient temperature & humidity condition. The life time of LED will be reduced. Operating life means brightness goes down to 50% initial brightness. Typical operating life time is estimated data.

Note4: The LED driving condition is defined for each LED module.

Technical Specifications

Model Number	DRS040-V1
Display Size	4.0 inches
Resolution	400(RGB)x960
Brightness	350 cd/m² (nits)
Interface Type	RGB24
Touch Screen	Capacitive / CTP Resistive Touch
Viewing Angle	170°+ (Full View)
Cover Lens	Black Glass / Anti-glare IPS
Operation Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C
Packing Size	20cm × 30cm × 40cm
Minimum Order Quantity	100 pieces

Product Advantages

IPS Full Viewing Angle: Ensures consistent color and brightness from all viewing directions, eliminating distortion and improving user experience.
Ultra-Low Power Consumption: Semi-transflective design allows use without backlight in natural light, reducing power usage for longer device battery life.
Easy Installation: 40PIN FPC flexible cable connection enables simple disassembly and assembly, suitable for space-constrained devices.
Stable Performance: ST7701 driver chip optimizes display functionality, ensuring smooth operation and accurate image rendering.
Global Compliance: RoHS compliant, meeting international environmental and safety standards for global market access.

Application Fields

This 4.0 Inch LCD TFT Screen is widely used in compact electronic devices across various industries, including:

Handheld devices (e.g., portable scanners, handheld terminals)
Mini home appliances (e.g., small smart controllers, compact display panels)
Consumer electronics (e.g., portable media players, small digital cameras)
Embedded systems (e.g., STM32/RK-based development projects, DIY electronic kits)
Portable medical devices (e.g., small blood glucose meters, portable monitors)
